pneumatic manipulator for heavy tube

The pneumatic manipulator is a mechanical device designed using the principles of pneumatics, which is used to achieve operations such as grasping, carrying and placing objects. Its design principle is mainly based on the compression, transmission and release of gas to achieve the movement and control of the manipulator. The following is a detailed introduction to the design principle of the pneumatic manipulator:

Design principle of pneumatic manipulator
Air supply: The manipulator usually provides compressed air as a power source through the air supply system. The air supply system usually consists of a compressed air source, an air pressure regulator, a filter, an oil mist collector and a pneumatic actuator. The air pressure generated by the compressed air source is adjusted to a suitable working pressure by the air pressure regulator, and then transported to the pneumatic actuator through a pipeline.
Pneumatic actuator: The pneumatic actuator is the core component of the manipulator, and a cylinder is usually used as the actuator. A piston is installed inside the cylinder, and the compressed air supplied by the air source drives the piston to reciprocate in the cylinder, thereby realizing the manipulator’s grasping, clamping, lifting and placement operations. The working modes of the cylinder are mainly single-acting cylinders and double-acting cylinders, which are used in different working scenarios.

we can customize different style,different size,different gripper according to different load.
